wiegand readers
X1-RX

IK10 Metal Wiegand Reader (E/H/MF)

IK10 anti collision
Metal Case, anti-vandal
Waterproof, conforms to IP67
Wiegand 26~44, 56, 58 bits output
Reading range: 2~6cm
External LED Control & External Buzzer Control
Card Type: 125KHz Hid & EM cards, 13.56MHz NXP Mifare, Mifare Plus, DesFire, Mifare Pro, Mifare UltraLight, Mifare Class 4K, NFC and CPU cards
IK10 Metal Wiegand Reader (E/H/MF)
IK10 Metal Wiegand Reader (E/H/MF)
IK10 Metal Wiegand Reader (E/H/MF)
Sales Inquiry

What card types does the IK10 Metal Wiegand Reader support?

The X1-RX is an IK10 certified reader, it is powerful in card reading type, can read 125KHz Hid &EM cards, 13.56MHz Mifare cards at the same time. Because of metal case anti-vandal and waterproof, it can be mounted either indoor or outdoor in harsh environment.

IK10 Metal Wiegand Reader card types: 125kHz HID & EM, 13.56MHz NXP Mifare (Plus, DesFire, Pro, UltraLight, Class 4K)
Card Type
125KHz HID & EMcards,13.56MHz  NXP Mifare,
Mifare Plus, DesFire,
Mifare Pro, Mifare UltraLight,
Mifare Class 4K cardscards

IP67 Waterproof
IK10 Metal Wiegand Reader with IP67 waterproof rating for outdoor access control


Remote control programming Wiegand output 26~44, 56, 58 bits on K10 metal wiegand reader

Equip with a remote control
can set the Wiegand output
from 26~44,56,58bits

-40°C
Low working temperature
IK10 Metal Wiegand Reader -40°C low working temperature


FAQ Of IK10 Reader

1. What does IK10 certification mean for this reader's durability?
IK10 is the highest impact protection rating, meaning the X1-RX withstands 20 joules of impact (equivalent to a 5kg weight dropped from 40cm). This makes it suitable for high-risk installations such as prisons, construction sites, public transit stations, or any area prone to vandalism or accidental heavy strikes—far beyond standard anti-vandal readers.

2. Which Wiegand output formats are supported for controller compatibility?
The X1-RX supports an exceptionally wide range: Wiegand 26 to 44 bits, plus 56 and 58 bits. This ensures compatibility with virtually any access control panel, including legacy systems, high-security government controllers, or specialized OEM boards that require non-standard bit lengths.
