access control keypad tampa
SK14

Keypad Access Control System

One relay, 10,000 users (9988 common users + 2 panic users +10 visitor users)
Card type: 125KHz EM card
Metal case, anti-vandal
Waterproof, conforms to IP67
Wiegand 26~44bits input & output
Can be used as Wiegand reader with LED & buzzer output
Card block enrollment
User data can be transferred
Build-in LDR for anti-tamer
2 devices can be interlocked for 2 doors
Backlit Keypad,can set automatic OFF after 20 seconds
WiFi function for optional
Keypad Access Control System
Keypad Access Control System
Keypad Access Control System
Keypad Access Control System
Sales Inquiry

Description of Keypad Access Control System

SK14 is Keypad Access Control, supports up to 9988 Card/PIN users, 2 panic users and 10 visitor users,
with Wiegand 26~44bits input & output, it can also work as a slave reader to connect to a 3rd party controller.

Features of Keypad Access Control System

10,000 EM Card or PIN standalone access control keypad
Big User Capacity:
10,000 PIN/Card Users

Backlit Keyapd
Tri-LED Displa
anti-vandal code keypad for access control
rfid keypad access control User Transfer

       Transfer users can be easily         done within one minute
Wiegand 26~44 input & output
virtual keypad access control
-40℃ outdoor keypad access control system
-40℃ resistance
IP67 waterproof

FAQ of Keypad Access Control System

1. What's SK14 Keypad Access Control?

SK14 is a waterproof standalone access controller with metal case.IP67 Waterproof makes it very suitable for outdoor use.It uses Atmel MCU assuring stable performance.The operation is very user-friendly, and low-power circuit makes long service life.It supports up to 9988 Card/PIN users, 2 panic users and 10 visitor users, with Wiegand 26~44bits input&output, it can also work as a slave reader to connect to a 3rd party controller.


2. Can the device operate reliably in sub-zero winters or scorching summer heat?
The device is built with industrial-grade wide-temperature components, typically operating within -40°C to +60°C. It features moisture-resistant circuitry and a durable keypad backlight. Whether in freezing northern climates or hot, humid southern regions, it maintains stable performance for card reading, PIN verification, and optional fingerprint recognition. The metal housing also aids heat dissipation and resists UV degradation.



3.  The product supports 10,000 users. Can it truly meet the needs of large enterprises or industrial parks with thousands of employees?
Yes, absolutely. The device features onboard storage for 10,000 users (including card numbers, PINs, and user IDs), making it well-suited for medium-sized campuses, multi-factory sites, and university dormitories.



4. I already have a third-party access control host and just want to upgrade to a more rugged front-end reader. Can this product work in that setup?
Absolutely. You can program the device to Reader mode by keypad, the device can be switched to pure reader mode. In this mode, it only reads cards/PINs and outputs data via Wiegand 26/34 protocol to the existing third-party controller. The rugged metal housing and backlit keypad instantly enhance the physical security and aesthetic consistency of your current system.
