S12-X EM+MF
Powerful Controller/Reader
1,000 card users
Card type: 125KHz EM +13.56MHz Mifare cards
Metal case, embedded design
Waterproof, conforms to IP67
Wiegand 26~44,56, 58 bits input & output
User data can be transferred by Wiegand line
Pulse mode, toggle mode
2pcs devices support interlock for two doors
Sales Inquiry
Description of Powerful Controller/Reader
The S12-X is a single door multi-function standalone access controller or a Wiegand reader. It supports 125KHz EM cards & 13.56MHz Mifare cards. IP 67 waterproof and anti-vandal metal housing make it suitable for outdoor use.
Features of Powerful Controller/Reader
EM & Mifare Dual Frequency
Support User Backup
Waterproof, Conforms to IP67
Convertibale Working Modes
FAQs of Powerful Controller/Reader
1. Is this device a standalone controller or a Wiegand reader?
It can work both as a standalone access controller and a Wiegand reader, providing flexible application in different access control systems.
2. What types of cards does this access controller support?
It supports 125KHz EM cards or 13.56MHz Mifare cards, covering most common RFID cards on the market.
3. What material is the case made of?
It is zinc-alloy metal case, which is vandal-resistant, sturdy and durable for long-term outdoor use.
4. Can users be copied from one device to another?
Yes, it supports transferring user data via Wiegand cables, making user management and data synchronization more convenient.
