wiegand proximity reader
S6-R

Metal Anti-Vandal Wiegand Reader (EM/HID) - IP67

Metal Case, anti-vandal
Waterproof, conforms to IP66
Wiegand 26~44 bits output programmable (default: 26bits)
Card type: EM & Hid card
Reading range: 1~4 cm
External LED Control & External Buzzer Control
Metal Anti-Vandal Wiegand Reader (EM/HID) - IP67
Metal Anti-Vandal Wiegand Reader (EM/HID) - IP67
Metal Anti-Vandal Wiegand Reader (EM/HID) - IP67
Sales Inquiry

What makes the S6-R reader suitable for indoor and outdoor harsh environments?

The S6-R reader is a metal case anti-vandal proximity reader.
Because of waterproof, it can be mounted either indoor or outdoor in harsh environments.

Key Features of the S6-R Metal Anti-Vandal Proximity Reader

S6-R wiegand proximity reader IP66 waterproof rating for outdoor access control



Waterproof IP67


Wiegand 26~37bits(default 26bits)
S6-R wiegand proximity reader Wiegand output 26-37 bits programmable, default 26 bits


Metal case anti-vandal construction of S6-R wiegand proximity reader




Metal Case, Anti-vandal

3 Kinds of Interface
Three interface options on S6-R wiegand proximity reader: cable, RJ45 connector and terminal block




S6-R wiegand proximity reader card type: 125kHz EM and HID proximity cards


Card Type: EM+HID

FAQ of Outdoor IP66 Wiegand Reader

1. How does the external LED and buzzer control enhance access control feedback?
The S6-R provides dedicated input terminals for external LED and buzzer control, allowing the host controller to directly manage visual and audible indicators. This enables clear user feedback—such as red/green status and grant/deny tones—without relying on the reader’s default behavior, which is especially useful in high-noise environments or where strict security verification is required.

2. Can this metal reader withstand harsh industrial conditions beyond standard outdoor use?
Yes. With a zinc-alloy metal case, IP66 sealing, and -40°C to 60°C operating range, the S6-R is built for heavy-duty applications such as chemical plants, car wash facilities, or food processing sites where frequent moisture, dust, or physical contact occur. Its fully potted electronics also resist vibration and impact.
