SK13
Outdoor Keypad & RFID Access
One relay, 10,000 users (9988 common users + 2 panic users +10 visitor users)
Card type: 125KHz EM card
Metal case, anti-vandal
Waterproof, conforms to IP67
Wiegand 26~44bits input & output
Can be used as Wiegand reader with LED & buzzer output
Card block enrollment
User data can be transferred
Build-in LDR for anti-tamer
2 devices can be interlocked for 2 doors
Backlit Keypad,can set automatic OFF after 20 seconds
WiFi function for optional
Sales Inquiry
Description of Outdoor Keypad & RFID Access
The device is a waterproof standalone access controller with metal case.
IP66 waterproof makes it very suitable for outdoor use. It uses Atmel MCU assuring stable performance.
The operation is very user-friendly, and low-power circuit makes long service life.
Features of Outdoor Keypad & RFID Access
Big User Capacity:
10,000 PIN/Card Users
10,000 PIN/Card Users
Backlit Keyapd
Tri-LED Display
Tri-LED Display
Transfer users can be easily done within one minute
Wiegand 26~44 input & output
-40℃ resistance
IP67 waterproof
FAQs of Outdoor Keypad & RFID Access
1. What is the SK13? What are its main functions?
The SK13 is a waterproof stnadalone access controller with metal case.IP67 Waterproof makes it very suitable for outdoor use.It uses Atmel MCU assuring stable performance.The operation is very user-friendly, and low-power circuit makes long service life.It supports up to 9988 Card/PIN users, 2 panic users and 10 visitor users, with Wiegand 26~44bits input&output, it can also work as a slave reader to connect to a 3rd party controller.
2. What's advantage of SK13 Keypad Access Control？
- Big User Capacity 10,000 Card or PIN Users include 9988 common users + 2 panic users + 10 visitor users;
- 2 devices can be interlocked for 2 doors,this function suitable for bank.
- WiFi Function for Optional (If choose WiFi function,it can open the door remotely);
- 3 Working Modes: Standalone,Controller,Reader;
3. What does"Keypad Wiegand Reader" mean for the SK13？
The SK13 has 3 working modes:
First, Standalone mode can connect with lock for working directly,it does not require connection to a centralized control host.
Second,as Controller mode,SK13 can connect with any Reader which support Wiegand 26~44bits output.
Third, SK13 also can work as Keypad Wiegand Reader,which connect with any Wigand 26~44bits input Controller,when reads the information of EM card or Press Keypad,it will sends the data to a connected access control controller through the Wiegand cabels.
