access control biometric fingerprint reader
SF2

IP67 Waterproof Fingerprint Access Control with Keypad

Waterproof, up to IP66
Metal Design & Anti-Vandal
Standalone, one relay
1,000 fingerprint, 2,000 PIN users
Wiegand 26~37 output
Pulse mode, toggle mode
Multi fingerprints/PINs access
Interlock, Support Principal User
IP67 Waterproof Fingerprint Access Control with Keypad
IP67 Waterproof Fingerprint Access Control with Keypad
IP67 Waterproof Fingerprint Access Control with Keypad
Sales Inquiry

What is SF2 waterproof fingerprint keypad access control?

SF2 is a waterproof standalone fingerprint access control with keypad and metal case. IP66
waterproof makes it very suitbale for outdoor use. It supports up to 1000 fingerprint users and 2000 PIN
users, with Wiegand 26~44 bits output, it can also work as a slave reader to connect to a 3rd party controller


What are the key features of SF2 fingerprint keypad access control?

SF2 metal case anti-vandal construction for high-security fingerprint access control

Metal Case, Anti-vandal


IP67 Waterproof
SF2 IP67 waterproof rating for outdoor fingerprint keypad access control
SF2 operating temperature -30°C to 60°C default, -40°C to 60°C optional for extreme cold environments

-30°C (Default)
-40°C (Optional)
Operating Temperature
         Higher Security PIN

For higher security,we allowyou to hide your correct PINwithin other numbers up tomax of 10 digits
SF2 fake PIN hiding function: hide correct PIN within up to 10 digits for higher security



 Two Working Modes:
SF2 working as standalone fingerprint access controller with built-in relay               Working as standalone
Working as slave reader
                                                                                                                                                                                                 SF2 working as Wiegand slave reader to connect with third-party access control panel








FAQ About SF2 Fingerprint Keypad Access Control

1. How does SF2 waterproof fingerprint access control work?
The SF2 is an IP66 waterproof standalone fingerprint keypad access control. It supports fingerprint, PIN code, and combined verification, stores up to 3000 users, and outputs relay signals to unlock doors. It also supports Wiegand 26–44 bits for system integration.



2. What is the user capacity of SF2 fingerprint keypad access control?
The SF2 biometric access control supports up to 1000 fingerprint users and 2000 PIN users, totaling 3000 users. The PIN length is 4–6 digits with fake PIN hiding function for enhanced security.



3. What Wiegand output does SF2 fingerprint reader support?
The SF2 waterproof FingerKey access control supports Wiegand 26–44 bits output. It can run as a standalone controller or a Wiegand slave reader to connect with any access control panel.



4. Does SF2 support alarm and relay adjustment?
Yes. The SF2 features adjustable relay output time (0–99s) and alarm output time (0–3min). It also supports door contact, exit button, and alarm interfaces for complete and secure access control management.
