access control and biometrics
SF1

Waterproof Fingerprint Access Control Reader

Waterproof, up to IP66
Metal Design & Anti-Vandal
Standalone, one relay
1,000 fingerprint/ card users
Wiegand 26~37 output
Pulse mode, toggle mode
Multi fingerprints/cards access
Interlock, Support Principal User
Waterproof Fingerprint Access Control Reader
Waterproof Fingerprint Access Control Reader
Waterproof Fingerprint Access Control Reader
Sales Inquiry

What is SF1 fingerprint access control and where can it be installed?

SF1 is a waterproof metal case standalone fingerprint access control with integrated EM reader.
IP66 waterproof makes it very suitable for outdoor use; with the slim design, it is an ideal choice to install on door frame.


What are the key features of SF1 fingerprint access control reader?

SF1 fingerprint access control IP67 waterproof rating for outdoor installation

IP67 Waterproof


-40℃ Operating Temperature
SF1 biometric access operates at -40°C low working temperature
biometric access metal case anti-vandal construction for high-security and harsh conditions

Metal Case, Anti-vandal
Wiegand 26~37bits (default 26bits)
biometrics reader access Wiegand output 26 to 37 bits programmable, default 26 bits
biometrics access SF1 two-door interlock function: two readers can be interlocked for sequential access control
2 devices
can be interlocked for 2 doors


FAQ About SF1 Fingerprint Access Control

1. How does SF1 waterproof fingerprint access control work?
The SF1 is an IP66 waterproof standalone fingerprint access control reader. It supports 125KHz EM card and fingerprint verification, stores up to 1000 users, and triggers relay output to unlock the door. It also provides Wiegand 26–37 bits output to work with a third-party access control panel.



2. Is SF1 fingerprint access control suitable for outdoor use?
Yes. The SF1 features IP66 waterproof, zinc-alloy anti-vandal housing, and a wide operating temperature from -30°C up to -40°C (optional). It is designed for outdoor gates, garage doors and harsh environment access control.



3. Does SF1 support multiple verification modes?
Yes. The SF1 waterproof fingerprint access control supports fingerprint only, card only, or multi‑fingerprint/card combined access. It also supports interlock and principal user management for higher security.
