H4-Key
Outdoor Encrypted Card Reader
Read Secukey anti-copy 13.56MHz Mifare card
Touch keypad with doorbell
One relay, 1000 users (988 common users + 2 panic users +10 visitor users)
Wiegand 26~44bits, 56bits, 58 bits input & output
Can be used as Wiegand reader with LED & buzzer output
User data can be transferred
Integrated alarm & Buzzer output
Built-in light dependent resistor(LDR) for anti tamper
Backlit keypad,can set automatic OFF after 20 seconds
2 devices can be interlocked for 2 doors
Sales Inquiry
Description of Outdoor Encrypted Card Reader
The device only read Secukey anti-copy card, this kind of card can't be cloned, copied, or read by unauthorized readers.
IP67 waterproof makes it very suitable for outdoor use. It supports up to 998 Card/PIN users and 2 panic users, with Wiegand 26~44, 56, 58
bits input & output, can work as standalone, controller or Wiegand reader.
Features of Outdoor Encrypted Card Reader
Read Secukey Anti-copy Card Only
Waterproof Touch Keypad With Backlit
3 Working Modes: Standalone/ Controller/ Reader
One Relay, 1,000 Users
Wiegand Input & Output
User Data Can Be Transferred By Wiegand Cables
FAQs of Outdoor Encrypted Card Reader
1. Which type of card does the device support?
The device only reads Secukey anti-copy cards. This type of card cannot be cloned, copied, or read by unauthorized readers, ensuring high security.
2. Is the device suitable for outdoor use?
Yes. It has an IP67 waterproof rating, which makes it very suitable for outdoor use and can withstand harsh outdoor environmental conditions.
3. How many users can the device support?
It supports up to 998 Card/PIN users and 2 panic users, meeting the needs of most small to medium-sized access control scenarios.
4. What working modes and Wiegand specifications does the device have?
It supports Wiegand 26~44, 56, 58 bits input & output, and can work in three modes: standalone, controller, or Wiegand reader.
