S11-X EM+MF
Convertible Controller/Reader
1,000 card users
Card type: 125KHz EM +13.56MHz Mifare cards
Metal case, embedded design
Waterproof, conforms to IP67
Wiegand 26~44,56, 58 bits input & output
User data can be transferred by Wiegand line
Pulse mode, toggle mode
2pcs devices support interlock for two doors
Sales Inquiry
Description of Convertible Controller/Reader
The S11-X is a single door multi-function standalone access controller or a Wiegand reader. It supports 125KHz EM cards & 13.56MHz Mifare cards. IP 67 waterproof and anti-vandal metal housing make it suitable for outdoor use.
Features of Convertible Controller/Reader
EM & Mifare Dual Frequency
Support User Backup
Waterproof, Conforms to IP67
Convertibale Working Modes
FAQs of Convertible Controller/Reader
1. What is the S11-X? What are its main functions?
The S11-X is a multi-functional device that can work as either a single door standalone access controller or a Wiegand reader. It is mainly used for access control management, enabling authorized access through compatible RFID cards, and its dual-mode design makes it flexible for different access control system configurations.
2. Which types of RFID cards does the S11-X support?
The S11-X supports two common types of RFID cards: 125KHz EM cards and 13.56MHz Mifare cards. These two types cover most basic to mid-range access control needs—125KHz EM cards are typically used for simple access control scenarios, while 13.56MHz Mifare cards offer higher data security and read/write capabilities for more demanding applications.
3. What does"standalone access controller"mean for the S11-X?
As a standalone access controller, the S11-X does not require connection to a centralized control host. All electronic components and access control logic are integrated into the device itself, making it easy to install and cost-effective, especially suitable for small facilities or single-door access control scenarios where centralized management is not needed.
4. What is a Wiegand reader, and how does the S11-X function in this mode?
A Wiegand reader is a device that uses the Wiegand protocol to read card data and transmit it to an access control controller via dedicated data lines. When the S11-X is used as a Wiegand reader, it reads the information of compatible EM or Mifare cards and sends the data to a connected access control controller through the Wiegand cabels, serving as a front-end card reading component of the access control system.
